Depureco Ecobull XM DEX Compact ATEX Blower Vacuum, 20 Litre

Name: Depureco Ecobull XM DEX Compact ATEX Blower Vacuum, 20 Litre
Brand: Depureco
SKU: A1790 / A1800 (1/3D) · A1805 / A1810 (1/2D)

Model code · A1790 / A1800 (1/3D) · A1805 / A1810 (1/2D)

A compact continuous duty ATEX vacuum. A certified side channel blower on a 20 litre body, with a 34,000 cm² antistatic cartridge and JetClean cleaning.

Request a quote/advice

Certification	ATEX, third-party certified — Zone 21 (1/2D) or Zone 22 (1/3D) version
ATEX marking	II 1/2D Ex h IIIC T160 Da/Db II 1/3D Ex h IIIC T160 Da/Dc
Type	Dry type (EN 17348)
Power	1.8 kW (2.4 HP) or 2.2 kW (3 HP)
Suction unit	ATEX certified side channel blower
Supply	230 V, 50/60 Hz
Duty	Continuous
Vacuum in continuous duty	180 mbar (18 kPa)
Maximum airflow	240 m³/h (approx. 141 CFM)
Inlet	50 mm with sliding damper
Bin	20 litres, AISI 304 stainless steel
Primary filter	M-class antistatic polyester cartridge, 34,000 cm²
Secondary filter	H14 fibreglass, 9,100 cm²
Filter cleaning	JetClean
Noise level	72 dB(A)
Footprint	516 × 545 mm
Height	1,050 mm
Weight	57 kg

About the Ecobull XM DEX

The Ecobull XM DEX puts a continuous duty ATEX blower on the smallest practical chassis. It is designed to sit beside a process — a mixer, a filling head, a tablet press, a weighing station — and run for the whole shift, collecting combustible dust at the point it is released.

The side channel blower carries its own ATEX certification and the collection chamber is certified to category 1D. JetClean keeps the antistatic cartridge clear without stopping, and the 20 litre stainless bin rolls out on castors. It is supplied as a 1/2D machine for Zone 21 or a 1/3D machine for Zone 22.

Key features

ATEX certified side channel blower for continuous duty
JetClean filter cleaning
Antistatic M-class cartridge filter, 34,000 cm²
H14 filter available
Internal chamber third-party certified to category 1D
20 litre AISI 304 stainless steel bin; stainless control panel; all components grounded

Depureco Ecobull XM DEX cutaway showing motor, filter, inlet and collection bin — Ecobull XM DEX — what is inside. Manufacturer’s illustration.

Certified to the European ATEX directive 2014/34/EU. Zone suitability must be matched to your site’s hazardous area classification — tell us the zone and the dust or gas group when you ask for a quote, and talk to your site safety team before specifying equipment for a classified area.
